host A、host B和host C通过接入交换机switch、 路由器router与internet通信。出于安全考虑，需要在路由器router上部署SecBlade插卡device起安全防护作用，应用需求如下：

·     switch将host A、host B和host C分别划分在VLAN 10、VLAN 20和VLAN 30，透传host与internet之间的流量 。

·     router与host、internet和device三层对接，下行口和Route-Aggregation1.100划分在VPN host， 上行口和Route-Aggregation1.200划分在VPN internet，查静态路由表转发host与internet之间的流量 。

·     device与router三层对接，查静态路由表转发host与internet之间的流量 。

图2 – 2  三层直路部署SecBlade插卡（划分vrf）组网图

交换机VRF，防火墙旁挂

‌

设备

接口

ip地址

设备

接口

ip地址

host A

–

192.168.10.15/24

device

RAGG1.100

10.1.1.2/30

host B

–

192.168.20.15/24



RAGG1.200

10.1.1.5/30

host C

–

192.168.30.15/24







router

GE1/0/1.10

192.168.10.1/24









GE1/0/1.20

192.168.20.1/24









GE1/0/1.30

192.168.30.1/24









RAGG1.100

10.1.1.1/30









RAGG1.200

10.1.1.6/30









1. 配置switch

#  创建VLAN 10、VLAN 20和VLAN 30，将GigabitEthernet1/0/1、GigabitEthernet1/0/2和GigabitEthernet1/0/3分别加入VLAN 10、VLAN 20和VLAN 30。

<switch> system-view

[switch] vlan 10

[switch-vlan10] port gigabitethernet 1/0/1

[switch-vlan10]  quit

[switch] vlan 20

[switch-vlan20] port gigabitethernet 1/0/2

[switch-vlan20]  quit

[switch] vlan 30

[switch-vlan30] port gigabitethernet 1/0/3

[switch-vlan30]  quit

#  将GigabitEthernet1/0/4的链路类型配置为trunk， 并允许VLAN 10、VLAN 20和VLAN 30的报文通过。

[switch] interface gigabitethernet 1/0/4

[switch-GigabitEthernet1/0/4]  port link – type trunk

[switch-GigabitEthernet1/0/4] port trunk permit vlan 10 20 30

[switch-GigabitEthernet1/0/4]  quit

2. 配置router

#  创建VPN实例host与internet。

[router]  ip vpn – instance host

[router-vpn-instance-host]  quit

[router] ip vpn-instance internet

[router-vpn-instance-internet]  quit

#  创建三层聚合接口1。

[router]  interface route – aggregation 1

[router-Route-Aggregation1]  quit

#  创建三层聚合子接口Route – Aggregation1.100和Route – Aggregation1.200，开启Dot1q终结功能，分别终结VLAN 100和VLAN 200， 绑定VPN实例并配置接口ip。

[router]  interface route – aggregation 1.100

[router-Route – Aggregation1.100]  vlan – type dot1q vid 100

[router-Route – Aggregation1.100]  ip binding vpn – instance host

[router-Route – Aggregation1.100] ip address 10.1.1.1 30

[router-Route – Aggregation1.100]  quit

[router]  interface route – aggregation 1.200

[router-Route – Aggregation1.200]  vlan – type dot1q vid 200

[router-Route – Aggregation1.200] ip binding vpn-instance internet

[router-Route – Aggregation1.200] ip address 10.1.1.6 30

[router-Route – Aggregation1.200]  quit

#  将FortyGigE2/0/1和FortyGigE2/0/2加入到聚合组1中。

[router] interface range fortygige 2/0/1 fortygige 2/0/2

[router-if-range]  port link – aggregation group 1

[router-if-range]  quit

#  创建三层子接口GigabitEthernet1/0/1.10、gigabitethernet1/0/1.20和GigabitEthernet1/0/1.30，开启Dot1q终结功能，分别终结VLAN 10、VLAN 20和VLAN 30， 绑定VPN实例并配置接口ip。

[router]  interface gigabitethernet 1/0/1.10

[router-GigabitEthernet1/0/1.10] vlan-type dot1q vid 10

[router-GigabitEthernet1/0/1.10]  ip binding vpn – instance host

[router-GigabitEthernet1/0/1.10] ip address 192.168.10.1 24

[router-GigabitEthernet1/0/1.10]  quit

[router] interface gigabitethernet 1/0/1.20

[router-gigabitethernet1/0/1.20] vlan-type dot1q vid 20

[router-gigabitethernet1/0/1.20]  ip binding vpn – instance host

[router-gigabitethernet1/0/1.20]  ip address 192.168.20.1 24

[router-gigabitethernet1/0/1.20]  quit

[router] interface gigabitethernet 1/0/1.30

[router-GigabitEthernet1/0/1.30]  vlan – type dot1q vid 30

[router-GigabitEthernet1/0/1.30]  ip binding vpn – instance host

[router-GigabitEthernet1/0/1.30]  ip address 192.168.30.1 24

[router-GigabitEthernet1/0/1.30]  quit

#  配置GigabitEthernet1/0/2接口ip， 绑定VPN实例。

[router]  interface gigabitethernet 1/0/2

[router-GigabitEthernet1/0/2] ip binding vpn-instance internet

[router-GigabitEthernet1/0/2]  ip address 20.1.1.1 24

[router-GigabitEthernet1/0/2]  quit

#  配置静态路由指导上下行流量转发。

[router] ip route-static vpn-instance host 20.1.1.0 24 vpn-instance host 10.1.1.2

[router] ip route-static vpn-instance internet 192.168.10.0 24 vpn-instance internet 10.1.1.5

[router]  ip route – static vpn – instance internet 192.168.20.0 24 vpn – instance internet 10.1.1.5

[router] ip route-static vpn-instance internet 192.168.30.0 24 vpn-instance internet 10.1.1.5

3. 配置device

#  创建三层聚合接口1。

<device> system-view

[device]  interface route – aggregation 1

[device-Route-Aggregation1]  quit

#  创建三层聚合子接口Route – Aggregation1.100和Route – Aggregation1.200，开启Dot1q终结功能，分别终结VLAN 100和VLAN 200，并配置接口ip。

[device]  interface route – aggregation 1.100

[device-Route – Aggregation1.100]  vlan – type dot1q vid 100

[device-Route – Aggregation1.100]  ip address 10.1.1.2 30

[device-Route – Aggregation1.100]  quit

[device]  interface route – aggregation 1.200

[device-Route – Aggregation1.200]  vlan – type dot1q vid 200

[device-Route – Aggregation1.200]  ip address 10.1.1.5 30

[device-Route – Aggregation1.200]  quit

#  将FortyGigE1/0/1和FortyGigE1/0/2加入到聚合组1中。

[device] interface range fortygige 1/0/1 fortygige 1/0/2

[device-if-range]  port link – aggregation group 1

[device-if-range]  quit

#  将Route – Aggregation1.100和Route – Aggregation1.200分别加入安全域Trust和untrust中 。

[device]  security – zone name trust

[device-security-zone-Trust] import interface route-aggregation 1.100

[device-security-zone-Trust]  quit

[device] security-zone name untrust

[device-security-zone-untrust] import interface route-aggregation 1.200

[device-security-zone-untrust]  quit

#  配置安全策略允许域间报文通过。

[device]  security – policy ip

[device-security-policy-ip] rule name trust-untrust

[device-security-policy-ip-0-trust-untrust]  action is pass pass

[device-security-policy-ip-0-trust-untrust] source-zone trust

[device-security-policy-ip-0-trust-untrust] destination-zone untrust

[device-security-policy-ip-0-trust-untrust]  quit

[device-security-policy-ip] rule name untrust-trust

[device-security-policy-ip-1-untrust-trust]  action is pass pass

[device-security-policy-ip-1-untrust-trust]  source – zone untrust

[device-security-policy-ip-1-untrust-trust] destination-zone trust

[device-security-policy-ip-1-untrust-trust]  quit

[device-security-policy-ip]  quit

#  配置静态路由指导上下行流量转发。

[device] ip route-static 192.168.10.0 24 10.1.1.1

[device] ip route-static 192.168.20.0 24 10.1.1.1

[device]  ip route – static 192.168.30.0 24 10.1.1.1

[device]  ip route – static 20.1.1.0 24 10.1.1.6

# host A上ping测试internet的连通性，可以ping通internet地址20.1.1.1。

C:\>ping 20.1.1.1

Pinging 20.1.1.1 with 32 bytes of data:

reply from 20.1.1.1 : bytes=32 time=3ms TTL=254

reply from 20.1.1.1 : bytes=32 time=2ms TTL=254

reply from 20.1.1.1 : bytes=32 time=1ms TTL=254

reply from 20.1.1.1 : bytes=32 time=2ms TTL=254



Ping statistic for 20.1.1.1 :

    Packets : sent = 4 , receive = 4 , lose = 0 ( 0 % loss ) ,

approximate round trip time in milli – second :

    Minimum = 1ms , Maximum = 3ms , average = 2ms

# host B上ping测试internet的连通性，可以ping通internet地址20.1.1.1。

C:\>ping 20.1.1.1

Pinging 20.1.1.1 with 32 bytes of data:

reply from 20.1.1.1 : bytes=32 time=3ms TTL=254

reply from 20.1.1.1 : bytes=32 time=2ms TTL=254

reply from 20.1.1.1 : bytes=32 time=1ms TTL=254

reply from 20.1.1.1 : bytes=32 time=2ms TTL=254



Ping statistic for 20.1.1.1 :

    Packets : sent = 4 , receive = 4 , lose = 0 ( 0 % loss ) ,

approximate round trip time in milli – second :

    Minimum = 1ms , Maximum = 3ms , average = 2ms

# host C上ping测试internet的连通性，可以ping通internet地址20.1.1.1。

C:\>ping 20.1.1.1

Pinging 20.1.1.1 with 32 bytes of data:

reply from 20.1.1.1 : bytes=32 time=3ms TTL=254

reply from 20.1.1.1 : bytes=32 time=2ms TTL=254

reply from 20.1.1.1 : bytes=32 time=1ms TTL=254

reply from 20.1.1.1 : bytes=32 time=2ms TTL=254



Ping statistic for 20.1.1.1 :

    Packets : sent = 4 , receive = 4 , lose = 0 ( 0 % loss ) ,

approximate round trip time in milli – second :

    Minimum = 1ms , Maximum = 3ms , average = 2ms

#  在device上检查会话表，存在host与20.1.1.1的会话表。

[device] display session table ipv4

slot 1 :

initiator :

  Source      ip/port: 192.168.10.15/12005

  Destination ip/port: 20.1.1.1/2048

  DS – Lite tunnel peer : –

  VPN instance / VLAN ID / Inline ID : -/-/-

  Protocol : ICMP(1 )

  Inbound interface: Route – Aggregation1.100

  Source security zone: Trust



initiator :

  Source      ip/port: 192.168.20.15/12005

  Destination ip/port: 20.1.1.1/2048

  DS – Lite tunnel peer : –

  VPN instance / VLAN ID / Inline ID : -/-/-

  Protocol : ICMP(1 )

  Inbound interface: Route – Aggregation1.100

  Source security zone: Trust



initiator :

  Source      ip/port: 192.168.30.15/12005

  Destination ip/port: 20.1.1.1/2048

  DS – Lite tunnel peer : –

  VPN instance / VLAN ID / Inline ID : -/-/-

  Protocol : ICMP(1 )

  Inbound interface: Route – Aggregation1.100

  Source security zone: Trust
