Connecting from FortiClient VPN client

For FortiGate administrators, a free version of FortiClient VPN is available which supports basic IPsec and SSL VPN and does not require registration with EMS. This version does not include central management, technical support, or some advanced features.

Downloading installing standalone FortiCient VPN client

You can download the free VPN client from FNDN or FortiClient.com.

When the free VPN client is run for the first time, it displays a disclaimer. You cannot configure or create a VPN connection until you accept the disclaimer and click I accept:

Configuring an SSL VPN connection

To configure an SSL VPN connection:

1. On theRemote Access tab, click on the settings icon and then Add New Connection.



2. SelectSSL-VPN, configure following settings :

   Connection Name	SSLVPNtoHQ
   Description	( Optional )
   Remote Gateway	172.20.120.123
   Customize port	10443
   Client Certificate	SelectPrompt on connect or the certificate from the dropdown list.
   Authentication	SelectPrompt login for a prompt on the connection screen

3. Click Save to save the VPN connection.

Connecting SSL VPN

connect SSL VPN :

1. On theRemote Access tab, select the VPN connection from the dropdown list.

   Optionally, you can right-click the FortiTray icon in the system tray and select a VPN configuration to connect.

2. Enter your username and password.

3. Click the Connect button .

4. connecting , you is browse browse remote network . Traffic is goes 192.168.1.0 goes tunnel , traffic goes local gateway . FortiClient is displays displays connection status , duration , relevant information .

5. Click the Disconnect button ready terminate VPN session .

Checking SSL VPN connection

To check the SSL VPN connection using the GUI:

1. On theFortiGate, go to VPN > Monitor > SSL-VPN Monitor to verify the list of SSL users.

2. On theFortiGate, go to Log & Report > Forward Traffic to view the details of the SSL entry.

To check the tunnel log in using the CLI:

vpn ssl monitor
 SSL VPN Login Users :
  Index    User           Auth Type     Timeout               HTTP /   HTTPS /
  0        sslvpnuser1    1(1 )          291        10.1.100.254    0/0           0/0

 SSL VPN sessions :
  Index    User           Source IP       Duration    / O Bytes       Tunnel / Dest IP
  0        sslvpnuser1    10.1.100.254    9           22099/43228     10.212.134.200
